Yarn Speed and Length Meter
Brand: SCHMIDT
Model: YS-20
Origin: Germany
Availability: In Stock
Combined hand-held tachometer:
– speed and length meter for filament and similar materials
– hand-held tachometer for contact and non-contact measurement e.g engine shafts
Tachometer with LCD display and 7 selectable measuring units
The most used yarn-speedmeter for circular knitting machines
Special Features
– Speed and length meter
– contact measuring of revolutions
– contact measuring of velocity of rotation
– non-contact measuring of revolutions
Linear Speed: meters/min, feet/min, inches/min
Length: meters, feet, inches
Revolutions: rpm
Standard Features
Available Models
| Model | Application | |
| YS-20 | speed and length meter as well as hand-held tachometer |
| Measuring ranges: | Yarn speed measurement 0.10 … 1999 m/min 0.40 … 6550 ft/min 4.00 … 78700 in/min 0.10 … 33.30 m/sec 0.10 … 109 ft/sec Yarn length measurement 0.00 … 99999 m 0.00 … 99999 ft 0.00 … 99999 in Revolution measurement Non-contact measurement: 1.00 … 99999 rpm Contact measurement: 0.10 … 19999 rpm |
| Accuracy: | ±0.2 % of displayed value ±1digit (not length measurement) |
| Measuring units: | Speed: m/min, ft/min, in/min, m/sec, ft/sec Length: m, ft, in Revolutions: rpm |
| Display: | 5 digit LCD, 10 mm high – floating decimal point |
| Measuring system: | Speed/Length: Slide-on measuring head with 30 mm diameter measuring wheel and wrapper roller Non-Contact Tachometer: Visible LED light beam Contact Tachometer: Slide-on measuring head with cone tip and surface speed wheel (10 cm circumference) |
| Yarn/wire diameter: | Yarn: max. 0.5 mm Wire: max 0.3 mm |
| Memory: | Min, Max, last reading, all retained in memory for the life of batteries |
| Sensing distance: | Max. 600 mm |
| Display update time: | 1 sec |
| Auto Power Off: | After 30 s of non-use |
| Temperature range: | 5 – 45 °C |
| Air humidity: | 85 % RH, max. |
| Power supply: | Batteries 2 x 1.5 V type AA (approx. 20 h continuous use) |
| Housing material: | ABS plastic |
| Dimensions: | 145 x 60 x 30 mm (LxWxH) |
| Weight, net (gross): | Approx. 150 g (700 g) |
Specifications subject to change without notice!
