Autoclaves (Vertical Type)
Brand: Jeio Tech
Model: ST-50G/65G/85G/105G
Origin: Korea
Availability: In Stock
Microprocessor control with reliable safety functions guarantees optimum sterilization temperature.
Features
Performance
- Microprocessor controller and temperature calibration function allows for high precision temperature control.
– Sterilization temperature at 110 to 123°C
– Melting* temperature at 60 to 100°C
* Liquefaction of coagulated agar media. - Automatic sterilization system for unattended operation.
– Heating > Check safe > Sterilization > Sterilization safe > Exhausting > End - Convenient operation modes for various uses.
– Standard modes and program modes are listed in detail as below tables. - Temperature calibration function.
| Standard modes | Temp.(°C) | Time(min.) |
|---|---|---|
| Decontamination | 121 | 35 |
| Solids sterilization | 121 | 20 |
| Liquids sterilization | 121 | 15 |
| Melting | 100 | 30 |
| Program modes | Temp.(°C) | Time(min.) |
|---|---|---|
| Sterilization 1 | 110 to 123 | 1 to 999 |
| Sterilization 2 | 110 to 123 | 1 to 999 |
| Liquid sterilization | 110 to 123 | 1 to 999 |
| Melting | 60 to 100 | 1 to 999 |
Convenience
- Conveniently monitored by an independent control display, sterilization process display, and pressure gauge.
– VFD for visualization of temp, pressure(optional), timer, warning alert checks.
– LED lamps for sterilization process check.
– Easy pressure check with the standard gauge attached to the front. - Vertical type autoclaves which allow for top loading are suitable for high volume sterilization.
– Baskets are stackable two high or even more levels, which secure inside the chamber space requirements. - Low-maintenance
– The chamber is constructed of stainless steel which is superiorly resistant to corrosion.
– Easy to replace silicone gasket. - Convenient documentation with the optional data recorder.
– Dot type recorder(6 point) allows for precise documentation. - Monitor via mobile app anytime, anywhere with LC Connected. (Requires LC GreenBox, option)
- Integrated with 21 CFR Part 11 compliant LC DataKeeper, suitable for GMP audits (option)
Safety
- Mechanical safety devices
– Over current protection.
– Over temperature protection by automatic power cutoff.
– Over pressure protection by automatic and manual safety valve. - Safety warning systems
– Over temperature warning.
– Low temperature warning.
– Low water level warning.
– Low heat warning if the temperature does not reach the sterilization or melting temperature.
– Sterilization fail warning if the operation is unexpectedly stopped during sterilization process.
Specification
| Model | ST-50G | ST-65G | ST-85G | ST-105G | |
|---|---|---|---|---|---|
| Control | Microprocessor PID control | ||||
| Chamber volume (L / cu ft) | 50 / 1.76 | 65 / 2.29 | 85 / 3.0 | 105 / 3.7 | |
| Temperature | Sterilization temp. (℃ / ℉) | 110 to 123 / 230 to 253.4 | |||
| Melting temp. (℃ / ℉) | 60 to 100 / 140 to 212 | ||||
| Pressure | Sterilization at 121℃ (kg/cm2) | 1.1 to 1.2 | |||
| Gauge range in analog (Mpa) | – 0.1 to 0.6 | ||||
| Permissible altitude (m) | Up to 800 | ||||
| Safety | Over temperature protector / Pressure safety valve / Over current protector | ||||
| Warning alert (over temp. / low temp. / low heat / sterilization fail / low water level) | |||||
| Timer | 0 to 999 min. | ||||
| Dimension | Interior (WxH) (mm / inch) | 400×458 / 15.75×18.03 | 400×558 / 15.75×21.97 | 400×758 / 15.75×29.84 | 400×908 / 15.75×35.75 |
| Exterior (W×D×H) (mm / inch) | 624x672x870
/ 24.57×26.46×34.25 |
624x672x971
/ 24.57×26.46×38.23 |
624x672x1083
/ 24.57×26.46×42.64 |
624x672x1233
/ 24.57×26.46×48.54 |
|
| Exterior with exhaust tank
(W×D×H) (mm / inch) |
722x672x870
/ 28.42×26.46×34.25 |
722x672x971
/ 28.42×26.46×38.23 |
722x672x1083
/ 28.42×26.46×42.64 |
722x672x1233
/ 28.42×26.46×48.54 |
|
| Door max. opening
(W×D×H) (mm / inch) |
1012x672x882
/ 39.84×26.46×34.72 |
1012x672x983
/ 39.84×26.46×38.7 |
1012x672x1095
/ 39.84×26.46×43.11 |
1012x672x1245
/ 39.84×26.46×49.01 |
|
| Basket (ØxH) (mm / inch) | 380×180 / 14.96×7.09 | 380×230 / 14.96×9.05 | 380×330 / 14.96×12.99 | 380×405 / 14.96×15.94 | |
| Net weight (Kg / lbs) | 94.5 / 208.34 | 99.5 / 219.36 | 104 / 229.28 | 110 / 242.51 | |
| Electrical requirements (230V, 50/60 Hz) | 14.3A | 14.3A | 14.3A | 21.3A | |
| Cat. No. | AAHL1015K | AAHL1025K | AAHL1035K | AAHL1045K | |
※ This product is not available for usage at an altitude higher than 800m.
Accessories and Options
-
Recorder (dot type)
-
Pressure Sensor
-
Exhaust Tank
-
Basket
-
Drain Bucket
-
Step Stool
Standard Accessories
| Cat. No. | Description | |
|---|---|---|
| AAAL1521 | Exhaust Tank | 5L, 114x387x281mm |
| AAAL1531 | Step Stool, Powder Coated Steel | 500x400x250mm |
| 00ATC0000091 | Drain Bucket | 490x291x107mm |
Optional Accessories
| Cat. No. | Description | |
|---|---|---|
| AAAL1501 | Recorder Set | Recorder (Dot, 6 points) & temp. sensor (Double) |
| AAAL1502 | Recorder Set | Recorder (Thermal Line) & temp. sensor (Double) |
| AAAL1511 | Pressure Sensor | 0~3.5 bar |
| 00ATC0000108 | temperature sensor for Recorder | |
※ The above option is only instolled when initial other.
Included and Maximum Basket Quantity
Baskets are stackable two high or even more levels, which secure inside the chamber space requirements as listed below.
| Cat. No. | Description | ST-50G (458mm) | ST-65G (558mm) | ST-85G (758mm) | ST-105G (908mm) | ||||
|---|---|---|---|---|---|---|---|---|---|
| Included | Maximum | Included | Maximum | Included | Maximum | Included | Maximum | ||
| 00ATC0000002 | Basket (Stainless steel, Ø380x180mm) |
2 | 2 | – | 2 | – | 3 | – | 4 |
| 00ATC0000003 | Basket (Stainless steel, Ø380x230mm) |
– | 1 | 2 | 2 | – | 2 | – | 3 |
| 00ATC0000004 | Basket (Stainless steel, Ø380x330mm) |
– | 1 | – | 1 | 2 | 2 | – | 2 |
| 00ATC0000126 | Basket (Stainless steel, Ø380x405mm) |
– | – | – | 1 | – | 1 | 2 | 2 |
* Above specifications can be changed without prior notice.
Flask Loading Capacity
At Max. loading capacity, partially without baskets.
| Description | Capacity | ST-50G (ea x floor) | ST-65G (ea x floor) | ST-85G (ea x floor) | ST-105G (ea x floor) |
|---|---|---|---|---|---|
| Erlenmeyer Flasks (O.D.xH, mm) | 250 mL (82 x 132) | 14×3 | 14×4 | 14×5 | 14×6 |
| 500 mL (101 x 176) | 8×2 | 8×3 | 8×4 | 8×4 | |
| 1000 mL (129 x 216) | 5×2 | 5×2 | 5×3 | 5×3 | |
| 2000 mL (160 x 268) | 3×1 | 3×2 | 3×2 | 3×3 | |
| Media Bottles (O.D.xH, mm) | 250 mL (70 x 143) | 20×3 | 20×3 | 20×5 | 20×6 |
| 500 mL (86 x 181) | 14×2 | 14×3 | 14×4 | 14×4 | |
| 1000 mL (101 x 230) | 8×1 | 8×2 | 8×3 | 8×3 | |
| 2000 mL (136 x 265) | 5×1 | 5×1 | 5×2 | 5×3 |
- LC GreenBox
(Mobile Monitoring System)
· Remote monitoring and control via mobile application.
· One LC GreenBox can connect up to 4 devices.
· Connect using RS-232 port on the communication port.
- LC DataKeeper
· High-integrity software compliant with FDA 21 CFR Part 11
· Integrated with Jeio Tech equipment to undergo GMP audits
Communication
| Ports | Cat. No. |
|---|---|
| Communication Port ¹⁾ | AAA125533 |
| LC GreenBox | AAHQ1011K |
| LC DataKeeper Basic ²⁾ | SSA11001 |
| LC DataKeeper Pro ²⁾ | SSA11002 |
Communication port is for connecting LC DataKeeper, LC GreenBox, and PC.
